Equipped with air conditioners for immediate use right after installation
| Daiwatech’s ecological houses use solar-powered natural energy, eliminating CO2 emissions and reducing the environmental burden. |
| With no need for commercial power supplies and electrical work, they can be installed safely, securely, and quickly |
| These houses are ideal for temporary offices at construction and civil engineering sites, headquarters bases and evacuation shelters in times of disasters or emergencies, temporary offices for events and meeting, mountain huts, or beach huts. When used as rest areas or waiting rooms for workers in agriculture, forestry, or fishery industries, these houses help ensure the safety of workers and prevent workplace accidents such as heatstroke. |
| The houses are equipped with air conditioners, floor carpets, and blinds. |
| The houses come fully charged when constructed and transported, so the air conditioners, lighting, etc., can be used immediately after installation. |
The house is equipped with an air conditioner, LED lighting, floor carpets, and blinds.
The box housing the storage battery can be used as a bench.
Display unit (LCD screen)
| The display unit features a 5.7-inch color LCD screen. |
| It shows messages when the remaining battery capacity drops to 20% and 5%, respectively. |
| All power supplies can be turned off to conserve electricity. |
| The display indicates the power storage amount (%), power generation (kW), and power consumption (kW). |
Storage battery box
The box housing the storage battery can be used as a bench.
LED sign panel
| The sign features a thin design and a clean frame shape. |
| It is suitable for posting announcements and as a signboard. |
| At night, it automatically turns on with a timer setting. It also serves as lighting for hands and feet during disasters. |
Standard LAN port
The display unit’s usage state can be confirmed in real time using a personal computer or smartphone.
* The standard communication rate is 128kbps. (Changeable as an option.)
House specifications (13.22 m2 size)
| Construction | Angular steel tubes, lightweight structural steel |
| Outer dimensions | 5,450(W)×2,300(D)×2,700(H) (including solar panels) |
| Surface area | 12.54 m² |
| Weight | 1,710 kg (including solar panels) |
| Wall material | Exterior walls: Metal siding / Interior walls: Printed plywood |
| Roof | Prepainted steel sheets (with condensation prevention agent) |
| Floor | Prepainted waterproof plywood |
| Insulation | Glass wool |
| Fixtures | Flush door, aluminum sash windows |
| Equipment | Air conditioner, LED lighting, ventilator, ventilation port, breaker, wall outlet, blinds, carpets, LED sign panel, modular jack for LAN connection |
* Varies by floor size
Electrical specifications (13.22 m2 size)
| Maximum solar panel output | 2.16 kW |
| Average expected daily power generation | Approx. 6 kWh (summer)/approx. 3.5 kWh (winter) |
| Cell type | Monocrystalline silicon |
| Controller | Charging management / backflow prevention |
| Solar panel charging method | MPPT (Maximum Power Point Tracking) |
| Storage battery type | Sealed battery |
| Environmental temperature | -10 to 45°C (with no condensation) |
| AC output | Single-phase 100V, 30A |
| Output waveform | Sine wave |
| Display unit (LCD) | Power storage amount (%), power generation (kW), power consumption (kW), main power supply (ON/OFF) |
| 100 VAC charging method | Commercial or generator |
* Varies by floor size
* The detailed specifications of the product are subject to change.
